DCB01CM24
Carlo Gavazzi DIN Rail Multi Function Timer Relay, 24 V dc, 24 → 240V ac, SPDT, 0.1 s → 100h
Timer Asymmetrical Recycler, DIN rail mount, 22,5x80x99,5mm Euronorm housing, selectable time ranges 0,1s – 100h, Supply voltage 24-240Vac and 24Vdc, Screw terminals connection, 8A SPDT relay output
Description
Specifications
| Attribute | Value |
| Supply Voltage | 24 V dc, 24 → 240V ac |
| Mounting Type | DIN Rail |
| Number of Contacts | 2 |
| Time Range | 0.1 s → 100h |
| Mode of Operation | Asymmetrical Recycler with Pulse Start |
| Number of Timer Functions | Multi Function |
| Contact Configuration | SPDT |
| Time Increment | Hours, Minutes, Seconds |
| Maximum Current | 8A |
| Power Supply | External |
| Terminal Type | Screw |
| Maximum Operating Temperature | +60°C |
| Depth | 83.5mm |
| Width | 22.5mm |
| Length | 99.5mm |
| Switch Configuration | SPDT |
| Contact Material | Silver Tin Oxide |
| Minimum Operating Temperature | -20°C |
| Time Delay | (On) ≤100 ms, (Off) ≤200ms |
